Class 1337HEHL
Panel Flanger Workstation, 3/4 GA, Heavy Duty High Lift, Top Belt Feed
Capabilities
Built for the production floor.
Every panel flanger workstation, 3/4 ga, heavy duty high lift, top belt feed is engineered for uptime, serviceability, and integration with the rest of your line.
- High Needle
- Lift – 1.25″ High
- Footlift – 1.25″ High
- Speed – 3500RPM
- Electronic DC Motor Perfectly Balanced Feeding Mechanism
- Heavy-duty sewing head with high pressure oiling system and filter
- Swing out presser foot with bearings reduces belt friction.
- Sews heavyweight & lightweight panels
- Adjustable flanger guide
- Unrestricted operator visibility
- Easy threading
- Sews faster, quieter and smoother.
- Guaranteed to require less maintenance and replacement parts than any other flanging machine 2-year warranty* *Call or write for a copy of our warranty.
Specifications & details
| Max sewing speed (spm) | 4000 |
|---|---|
| Factory preset speed (spm) | 3500 |
| Max stitch length (spi) | 5-6 |
| Needle system | SNTVC722-14068 |
| Needle size | 22/140 |
| Needle distance (in) | 3/4 – 1/4 |
| Weight of material | LIGHT / MEDIUM / HEAVY |
| Voltage (v/ph/hz) | 220V 1PH 60HZ |
| Current (amps) | 5 |
| Motor type | EFKA DC |
| Air pressure (psi) | 70 |
| Air consumption (scfm) | 12 |
| Shipping weight (lbs) | 600 |
| Shipping dimensions (w/l/h, inch) | 55 x 60 x 48 |
Production
Machine Model
90-110 Panels per hr
Models & options
- 1337046Pneumatic flanging cutter
- 1337ATSingle pneumatic flotation table
- 1337ATBSingle air table, drop-down shelf
- 1335001Triple pneumatic flotation table
- 1337022Single air table extension, 18′
- 1337ATEAir table double 11337HELJ28C
