Capabilities
Built for the production floor.
Every automatic vertical handle machine is engineered for uptime, serviceability, and integration with the rest of your line.
- Auto Border Serger Auto Border
- Serger & Optional Rewind Auto Border
- Measure & Cut with Optional Closer Auto Vertical Handle Machine Auto Vertical Handle
- Machine with Optional Closer Auto Vertical Handle
- Machine with Marking Module
- Two queen size borders per minute with 4 handles
- Border widths up to 18″
- Pre-made handles from 1.5″ to 3″ wide
- Dual safety stitch overlocks for extra strength 2, 4, 6 or 8 handles may be automatically sewn into border seams
- May be used as a plain border serger without handles
- Precise measurement and handle placement Serial Bus Control
- System with a 3-year unconditional warranty
Specifications & details
| Max sewing speed (rpm) | 5000 6000 |
|---|---|
| Factory preset speed (rpm) | 1800 ± 5% 5000± 5% |
| Max stitch length (spi) | 6 6 |
| Needle system | SNDLX1140 SNB27140 |
| Needle size | 22-140 |
| Weight of material | MEDIUM |
| Voltage (v/ph/hz) | 220V 1PH 60HZ |
| Current (amps) | 15 |
| Motor type | DC SERVO |
| Air pressure (psi) | 80 |
| Air consumption (scfm) | 14 Shipping |
| Weight (lbs) | 2200 100 Pieces per hour with 4 handles 90 Pieces per hour with closer with 4 handles (*) Actual production figures may vary depending on the roll size and stitch length. Border Closer / Cerradora de Borde Overlock / Sobrehilado |
Production
Machine Model Closer Overlock
Models & options
- 4300200Closer Station
- 1330200Re-winder
- MMSPOOL – Plastic Spool
- 4300320Marking Module – right
- 4300325Marking Module – left 4300B – Automatic Vertical Handle Inserter. Double Overedge the border, insert handles, measure and cut to length. Border width from 8.5″ to 18” 4300BN – Automatic Vertical Handle Inserter. Double Overedge the border, insert handles, measure and cut to length. Border width from 6.5″ to 18” 4300BNN – Automatic Vertical Handle Inserter. Double Overedge the border, insert handles, measure and cut to length. Border width from 5.0” to 18”
